Description
- Marchio: Blackmagic Design
- Categoria: Schede di Acquisizione e Registratori Video
- SDI Video Inputs: 1
- SDI Video Outputs: 1
- SDI Rates: 270Mb, 1.5G, 3G.
- HDMI Video Outputs: 1
- Screen: 2.2 inch LCD
- Time Code Connections: 1 x BNC In, 1 x BNC Out.
- Reference Connections: 1 x BNC In, 1 x BNC Out. Tri-Sync or Black Burst.
- SDI Audio Inputs: 16 channels embedded audio.
- SDI Audio Outputs: 16 channels embedded audio.
- HDMI Audio Outputs: 8 channels embedded audio.
- Remote Control: 1 x RS-422 In.
- Recorder Configuration: Via user interface or Blackmagic HyperDeck Ethernet Protocol.
- Ethernet: 1Gb/s
- Computer Interface: 1 x USB Type-C 3.0 (up to 5Gb/s) for external drive recording, webcam out, software configuration and updates.
Standards
- SD Video Standards: 525i59.94 NTSC, 625i50 PAL
- HD Video Standards:
- 720p50, 720p59.94, 720p60
- 1080i50, 1080i59.94, 1080i60
- 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
- 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
- 2K DCI Video Standards: 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI
- SDI Compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2084 and SMPTE 2108‑1.
- SDI Metadata
